Attwood 14230-3 Single Pole 4-Way Selector Marine Battery Switch
See current price
Check the current price and availability on Amazon.com.
View on AmazonAffiliate link — we may earn a commission at no extra cost to you. Learn more
- Current Rating
- 300 Amps
- Operating Voltage
- 32 Volts
- Brand
- attwood
- Terminal
- Spst
Key features
- Versatile; use for 6-volt to 32-volt D. C. (direct current) systems
- Rated for 300 amps continuous use at 6 volts and 150 amps continuous use at 12 volts
- Includes an automatic alternator field circuit disconnect to prevent surges and so, protect your valuable boat electronics
- Rugged build features Bakelite housing, copper washers, and solid brass terminals and nuts
- Attwood products are both compatible and reliable, engineered and built with a never-fail attitude
- Sport type: Boating
Specifications
| Operation Mode | Automatic |
|---|---|
| Current Rating | 300 Amps |
| Operating Voltage | 32 Volts |
| Brand | attwood |
| Terminal | Spst |
| Material | other |
| Item Dimensions LxWxH | 11.25 x 14.75 x 5.75 inches |
| Circuit Type | 4-way |
| Actuator Type | Rotary |
| International Protection Rating | IP54 |
| Number of Positions | 4 |
| Color | Unspecified |
| Unit Count | 1 Count |
| Number of Items | 1 |
| Item Package Dimensions L x W x H | 8.15 x 6.89 x 2.8 inches |
| Package Weight | 0.32 Kilograms |
| Item Weight | 1 Grams |
| Brand Name | attwood |
| Model Name | Attwood Boating Battery Switches |
| Suggested Users | unisex-adult |
| Manufacturer | Attwood |
| Part Number | 14230-3 |
| Included Components | 4-Way Battery Selector Switch |
| Size | One Size |
| Sport Type | Boating |
| ASIN | B0000AZ7X6 |
About this product
Dial in the exact power level you need. Single-pole, triple-throw switch has four connection modes: battery 1, battery 2, both batteries in parallel, or both off. Rugged build of Bakelite, copper, and solid brass stands up to tough marine conditions. Attwood Corporation has been an award-winning leader in engineering, testing, and manufacturing the highest quality marine products for over 100 years. We deliver safe and reliable lighting, fuel systems, water systems, seating & pedestals, swim ladders, custom upholstery, and general marine accessories that are easy to install and meet regulatory compliance.
