Glarks
Glarks 315Pcs Quick Splice 2.8mm 4.8mm 6.3mm Male and Female Wire Spade Connector Wire Crimp Terminal Block with Insulating Sleeve Assortment Kit
See current price
Check the current price and availability on Amazon.com.
View on AmazonAffiliate link — we may earn a commission at no extra cost to you. Learn more
- Contact Material
- Copper
- Insulation Material
- Nylon
- Terminal
- Bullet Terminal
- Brand
- Glarks
Key features
- Product Type: High quality wire crimp terminal block with insulating sleeve assortment kit
- Product Meterial: The terminal block are made of tin-plated red copper and the insulating sleeves are made of nylon, high conductivity, anti-oxidation, durable enough for your use
- Package Include: In this kit, it include 2.8mm/4.8mm/6.3mm male and female crimp terminal connector block 210pcs and 105pcs insulating sleeves total 315pcs packed in a plastic box
- Easy to Use: You just need to connect the male and female terminals at both ends, and then the male and female terminals docked to complete the wiring easily
- Application: These spade terminal can be widely used to home appliances, auto, audio system for battery or rocker switch quick connecting/disconnecting
Specifications
| Connector Type | Crimp |
|---|---|
| Contact Material | Copper |
| Insulation Material | Nylon |
| Terminal | Bullet Terminal |
| Brand | Glarks |
| Package Dimensions | 6.77 x 3.86 x 0.87 inches; 5.29 Ounces |
| Item model number | GLLALDZ-315 |
| Manufacturer | Glarks |
| ASIN | B099ZWZLKX |
About this product
Glarks high quality wire crimp terminal block with insulating sleeve assortment kit Specifications: Product Material: Tin-plated red copper and nylon Terminal Type: 2.8mm, 4.8mm, 6.3mm Specific dimensions: 6.3 Type: Inner diameter: 6.3mm, thickness: 0.4mm(male),0.8mm(female), compatible wire: 0.75-2.5mm(AWG 18-14) 4.8 Type: Inner diameter: 4.8mm, thickness: 0.35mm(male),0.5mm(female), compatible wire: 0.75-2.5mm2(AWG 18-14) 2.8 Type: Inner diameter: 2.8mm, thickness: 0.25mm(male),0.5mm(female), compatible wire: 0.5-1.5mm2(AWG 22-16) Package Detail: 2.8MM Male Spade Terminal -------------- 35pcs 2.8MM Female Spade Terminal ----------- 35pcs 4.8MM Male Spade Terminal -------------- 35pcs 4.8MM Female Spade Terminal ----------- 35pcs 6.3MM Male Spade Terminal -------------- 35pcs 6.3MM Female Spade Terminal ----------- 35pcs 2.8MM Insulating Sleeve ------------------- 35pcs 4.8MM Insulating Sleeve ------------------- 35pcs 6.3MM Insulating Sleeve ------------------- 35pcs Total Quantity: 315Pcs Application: Male and female bullet terminal wire connector with clear cover, ideal for car, motorcycle, truck, marine,quad bike, scooter, boats, electric instruments Warm Note: The product is manually measured, there may be an error of 0.01-0.03mm, please don't mind, thank you for your support.
