Milton (S-224) G-Style Coupler, Plug and Air hose Reducer Bushing Kit – 5 Pieces
See current price
Check the current price and availability on Amazon.com.
View on AmazonAffiliate link — we may earn a commission at no extra cost to you. Learn more
- Material
- Brass, Steel
- Brand
- Milton
- Color
- Steel
- Item Dimensions LxWxH
- 5 x 5 x 1 inches
Key features
- G-STYLE: Milton's G couplers and plugs have the highest SCFM rating. 2 plug styles are available, both have same function
- SIZE: 1/2" body size air fitting. 1/2" NPT. Buna-N seals. (G-Style offered in .125 or .375 critical profile dimension tip sizes.) 3/4" MNPT x 1/2” FNPT brass reducer bushing
- USE: These couplers are intended for air shop use only. Pneumatic applications that require over 60+ SCFM.
- MAXIMUM: 99 SCFM air flow. 300 PSI max inlet pressure. Temperatures up to 250 degrees F.
- QUALITY: Durable steel-plated couplers. Case-hardened steel plugs. Both plated to resist rust and corrosion.
- Milton is your number 1 source for Quality Air Accessories
- Since 1943 Milton has been producing Quality Air Accessories
- Milton covers automotive, industrial, hardware, agriculture, heavy-duty fleet and MRO markets
Specifications
| Size | 1 |
|---|---|
| Material | Brass, Steel |
| Brand | Milton |
| Color | Steel |
| Item Dimensions LxWxH | 5 x 5 x 1 inches |
| Connector Type | Reducer |
| Exterior Finish | Brass |
| Thread Type | NPT |
| Item Weight | 0.1 Pounds |
| Number of Pieces | 5 |
| Manufacturer | Milton |
| Part Number | S-224 |
| Product Dimensions | 5 x 5 x 1 inches |
| Country of Origin | USA |
| Item model number | s-224 |
| Item Package Quantity | 1 |
| Number of Handles | 1 |
| Special Features | G-STYLE: Milton's G couplers and plugs have the highest SCFM rating. 2 plug styles are available, both have same function -SIZE: 1/2" body size air fitting. 1/2" NPT. Buna-N seals. 3/4" MNPT x 1/2” FNPT brass reducer bushing -USE: These couplers are intended for air shop use only. Pneumatic applications that require over 60+ SCFM. Temperatures up to 250 degrees F. -QUALITY: Durable steel-plated couplers. Case-hardened steel plugs. Both plated to resist rust and corrosion. - - |
| Included Components | 1 Milton Branded Product |
| Batteries Required? | No |
| Domestic Shipping | Item can be shipped within U.S. |
| International Shipping | This item can be shipped to select countries outside of the U.S. Learn More |
| ASIN | B004HL7TYS |
About this product
Milton (S-224) G-Style Coupler, Plug and Air hose Reducer Bushing Kit – 5 Pieces Milton’s 5 piece G-Style couplers, plugs and reducer kit are the highest SCFM rated and are used in applications that require over 60 SCFM. These 1/2" Male and Female NPT G-style plugs offer 2 different sizes (.125 or .375 critical profile dimension tip sizes) which can function with both 1/2” Male and Female G-style coupler. This kit has a 1/2" basic flow size, with a maximum air flow of 99 standard cubic feet per minute and 300 PSI max inlet pressure. Made of durable steel, plated to resist rust. The kit also includes a 3/4” MNPT x 1/2” FNPT Hose reducer bushing to provide you the ability to assemble a new air hose or replace old fittings when reduction in pipe size is required.
